Conveyor Working For Forwarder Goods

Payment Terms: T/T,WU,
Place of Origin: Hebei, China (Mainland)
inquire skype
Add to My Favorites
HiSupplier Escrow
Share |

Product Detail

Means of Transport: Ocean,Land,
Packing: as your requirements
Use: Waste Plastic Crusher
Plastic type: PP PE FILM
capacity: 300-2000kg/hr
machine: cost of plastic recycling m...
Production Capacity: 5 sets everyday
Delivery Date: within 7 days
Brand Name: Haorui
process: crushing washing drying
advantage: compact and durable

Packing: Standard Export Packing
Origin: China
HS Code: 84778000
Production Capacity: 500 Lines/Year Plastic Pet Recycling

Specifications
The conveyor belt is ideal for dosing and loading of each type of materials.
it consists of a hopper with dosing device for dosing and by a pulley for the magnetic separation.
tape size; width=60cm,length=600cm
Conveyor size:
Machine type
Machine name
Rubber belt thickness
Length(cm)
Width(cm)
Height(cm)
Motor(KW)
wheel proportion
Net weight(not including motor)
note
60type
conveyor
1cm
400cm
85cm
50cm
2.2KW
30:1
250KG
machine can be customized
60type
conveyor
1cm
600cm
85cm
50cm
2.2KW
30:1
275KG
Machine can be customized
80type
conveyor
1cm
400cm
105cm
50cm
2.2KW
30:1
300KG
machine can be customized
80type
conveyor
1cm
600cm
105cm
60cm
2.2KW
30:1
500KG
Machine can be customized
100type
conveyor
1cm
800cm
120cm
60cm
3KW
30:1
800KG
Machine can be customized
1,high quality
2,length and height can be adjusted
3,can be customized
4, magnet inside
5, excellent after-sales service
features:
1, Convey the plastic bottles or other waste plastic to certain machines.
2, It can save the labors dramatically.
3, It can make the bottles entering into the machines well-proportioned.
4, Can be made on your require.
5, There is strong magnet inside, so it can remove the iron impurity

In use process, if there is a running deviation, and then to make the following checks to determine reasons, to adjust. Conveyor belt running deviation often check the parts and the processing method are:
(1) check the roller center line of the transverse and longitudinal center line of belt conveyor is not coincidence degree. Value is more than 3 mm, if you don't contact ratio should be used on either side of the roller set long hole on the installation and adjustment. Specific methods is a conveyor belt to which side, supporting roller group which side to the direction of the conveyor belt move forward, backward or the other side.
(2) check the head and tail frame installation deviation values of the two surfaces of the bearing. If deviation is greater than 1 mm in the plane of the two, the response to two plane adjustment in the same plane. Head roller adjustment method is: if the conveyor belt to the right side of the roller running deviation, the cylinder on the right side of the bearing should move forward or on the left side of the bearing pedestal ward; If conveyor belt to the cylinder on the left side of the wandering, the roller bearing should move forward or right on the left side of the bearing seat. The tail roller adjustment method is contrary to the head roller.
(3) check the location of the material on the conveyor belt. Material on the conveyor belt transect is not centered, will lead to the conveyor belt running deviation.
If the material slants to the right, the belt running deviation, and to the left and vice versa. When use should as far as possible let the material in the middle. To reduce or avoid this kind of conveyor belt running deviation can increase the baffle plate, change the direction of the material and location.
